噴淋清洗機防止串水的措施主要依賴于其獨特的設計和操作流程。以下是一些關鍵的防止串水的方法：

　　The measures to prevent water leakage in spray cleaning machines mainly rely on their unique design and operating procedures. Here are some key methods to prevent water leakage:

　　一、結構設計

　　1、 Structural Design

　　暗道結構：

　　Underpass structure:

　　采用暗道結構的設計，使得水霧不會擾動和回流。

　　The design adopts a hidden channel structure to prevent water mist from disturbing and flowing back.

　　各主要污染區域之間設計有完全隔段，并配有各自獨立的抽風口。

　　There are complete partitions designed between each major polluted area, and each area is equipped with its own independent exhaust outlet.

　　暗道在兩個端頭均配有引流口，霧氣會從引流口進入，并在中間通風豎隔板和導流橫隔板的作用下，防止水霧進入下一工作區域。

　　The hidden passage is equipped with drainage ports at both ends, and mist will enter through the drainage ports. Under the action of the middle ventilation vertical partition and the diversion horizontal partition, water mist will be prevented from entering the next working area.

　　分區設計：

　　Partition design:

　　噴淋清洗機通常分為多個工作區域，如化學噴淋區域、漂洗噴淋區域和干燥區域。

　　Spray cleaning machines are usually divided into multiple working areas, such as chemical spray area, rinse spray area, and drying area.

　　每個區域都設計有獨立的腔體和排水系統，以避免水霧或水滴在不同區域之間串流。

　　Each area is designed with independent chambers and drainage systems to prevent water mist or droplets from flowing between different areas.

　　二、操作流程

　　2、 Operation process

　　化學噴淋區域操作：

　　Chemical spray area operation:

　　在化學噴淋區域，主工作腔體進行噴淋產生大量化學水霧。

　　In the chemical spraying area, the main working chamber produces a large amount of chemical water mist during spraying.

　　水霧在抽風引流的作用下自然向暗道上流，同時主工作腔體的風刀產生的氣流會將水霧帶入化學次工作腔體。

　　The water mist naturally flows upward towards the dark passage under the action of ventilation and drainage, and at the same time, the airflow generated by the wind blade in the main working chamber will bring the water mist into the chemical secondary working chamber.

　　化學次工作腔體的頂部也設計有暗腔，次工作腔體的水霧同樣在抽風引流的作用下自然向上進入暗道。

　　The top of the chemical secondary working chamber is also designed with a dark chamber, and the water mist in the secondary working chamber naturally enters the dark passage upwards under the action of ventilation and drainage.

　　漂洗噴淋區域操作：

　　Rinsing spray area operation:

　　在漂洗噴淋區域，主工作腔體進行漂洗噴淋產生大量水霧。

　　In the rinsing spray area, the main working chamber generates a large amount of water mist during rinsing spray.

　　水霧在抽風的引流作用下被引入暗道并被抽走。

　　The water mist is introduced into the dark passage and drawn away by the drainage effect of the exhaust.

　　漂洗次工作腔體因風刀風切擾動帶入的水霧也通過抽風引流作用被帶入暗道并抽走。

　　The water mist brought in by the disturbance of the wind blade in the rinsing chamber is also carried into the dark passage and extracted through the suction and drainage effect.

　　干燥區域操作：

　　Dry area operation:

　　在干燥區域，主工作腔體由于風刀的熱切或冷切效果產生的水氣通過抽風的引流作用被帶入暗腔并抽走。

　　In the dry area, the water vapor generated by the hot cutting or cold cutting effect of the wind knife in the main working chamber is carried into the dark chamber and extracted through the drainage effect of the exhaust.

　　三、其他措施

　　3、 Other measures

　　使用止逆閥：

　　Use check valve:

　　在某些噴淋清洗機的設計中，可能會使用止逆閥來防止水流的反向流動，從而避免串水現象的發生。

　　In the design of some spray cleaning machines, check valves may be used to prevent the reverse flow of water and avoid the occurrence of water leakage.

　　定期維護和檢查：

　　Regular maintenance and inspection:

　　定期對噴淋清洗機進行維護和檢查，確保各個部件的正常運行和密封性能。

　　Regularly maintain and inspect the spray cleaning machine to ensure the normal operation and sealing performance of each component.

　　檢查排水系統是否暢通無阻，避免因堵塞而導致的水流不暢或串水現象。

　　Check whether the drainage system is unobstructed to avoid water flow obstruction or water leakage caused by blockage.

　　合理操作和使用：

　　Reasonable operation and use:

　　操作人員應按照設備的使用說明書和操作規程進行合理操作和使用。

　　Operators should operate and use the equipment reasonably according to the user manual and operating procedures.

　　避免在設備運行時進行不必要的調整或維修，以免對設備的正常運行造成影響。

　　Avoid unnecessary adjustments or maintenance during device operation to avoid affecting the normal operation of the equipment.

　　綜上所述，噴淋清洗機通過其獨特的設計和操作流程來防止串水現象的發生。同時，定期的維護和檢查以及合理的操作和使用也是確保設備正常運行和防止串水的重要措施。

　　In summary, the spray cleaning machine prevents water leakage through its unique design and operation process. At the same time, regular maintenance and inspection, as well as reasonable operation and use, are also important measures to ensure the normal operation of equipment and prevent water leakage.
